Products Description
MIGO Ultra Clear Patterned Solar Glass is extra-clear low-iron glass with a prismatic pattern on one side and a matt pattern on the other. It is designed to improve light transmission for solar applications while providing a controlled surface appearance. The glass is fully tempered and can be supplied with optional anti-reflective coating on the matt side.
Products Description
| Item | Specification |
|---|---|
| Glass Type | Ultra Clear Low Iron Patterned Glass |
| Thickness | 3.2mm, 4.0mm |
| Pattern | Prismatic / Matt |
| Iron Content (Fe₂O₃) | ≤120 ppm |
| Thickness Tolerance | ±0.2mm |
| Dimension Tolerance | ±1.0mm |
| Overall Bow/Warp | <0.2% |
| Local Warp | ≤0.3mm / 300mm |
| Fragmentation Test | ≥79 particles within 50×50mm |
| Tempering | Fully Tempered, EN12150 |
| AR Coating | Optional |
| Surface | Prismatic / Matt |
Mechanical & Thermal Characteristics
| Property | Value |
|---|---|
| Scratch Hardness | 4–5 |
| Poisson's Ratio | 0.2 |
| Density | 2.5 × 10³ kg/m³ |
| Tensile Strength | 42 N/mm² |
| Pressure Resistance | 700–900 N/mm² |
| Four Point Bending Test | ≥146.7 N/mm² |
| Thermal Conductivity | ≤1.36 W/(m·K) |
Applications
- Photovoltaic module cover glass
- Solar thermal collectors
- Solar water heaters
- Greenhouse roofs and walls
FAQ
1. What is Ultra Clear Patterned Solar Glass?
It is specially designed solar glass with a prismatic surface and a matt surface for efficient light transmission and reduced reflection.
2. What are the main benefits of this solar glass?
It offers high light transmission, low iron content, good durability, and a non-blinding surface appearance.
3. Where can Ultra Clear Patterned Solar Glass be used?
It is suitable for photovoltaic modules, solar thermal collectors, solar water heaters, and greenhouse applications.
4. Can the glass be customized?
Yes. MIGO can provide customized glass solutions according to project requirements, including size and optional surface coating.
